Project Report on H.T. & L.T. Insulator, Ht Air Brake Switches D.O. Fuse, Lightning Arresters

Project Report on H.T. & L.T. Insulator, Ht Air Brake Switches D.O. Fuse, Lightning  Arresters
Project Report on H.T. & L.T. Insulator, Ht Air Brake Switches D.O. Fuse, Lightning Arresters
Product Code : Project Report
Brand Name : ITI
Product Description
H.T. & L.T. Insulator, Ht Air Brake Switches D.O. Fuse, Lightning Arresters

Materials  having  few free electrons poor  conductors  In  fact, materials  that  have hardly any free electrons can  be  used  to insulate electricity and are called insulators, as glass, mica, porcelain,  rubber & paper. The  function of  an insulator is to  insulate  the  line conductor  from  each other and  from the pole or tower.  Three colours of insulator are used  in  over head  lines, namely. The  pin  insulator gets its name  from  the fact  that   it  is supported  on  a  pin.  The pin holds the  insulator,  and  the insulator  has the conductor tied on it. Pin insulators  are   made of  either glass or porcelain.  The  glass insulator  is always  one solid  piece  of glass, that is  it is one   piece  insulator.  The porcelain  insulator is also  a  one piece  insulator when  used  on low  voltage  lines but  consists of  two, three  or  four  layers, cemented  together to form a rigid  until when  used  on  higher voltage  line. It is  usually one  piece for voltage  below  23,000 volts.  The use of  several layers  for  high voltage line helps  to spill the rain and provide a long,  dry  arc-over  path.  Pin insulator are seldom used  on transmission lines  having  voltage above  4400   volts, although  some 88000 volts,  lines  using  pin insulators are  in operation today.

Cost Estimation
Plant Capacity    2 Ton/Day (HT/LT Insulator)
500 Nos/Day (HT Air Brake Switch and DO Fuse)
100 Nos/Day (Lightening Arrestor)
Land & Building (Area 6000 sq.mt.)  Rs. 7.60 Cr.
Plant & Machinery  Rs. 1.12 Cr.
W.C. for 3 Months  Rs. 1.45 Cr.
Total Capital Investment  Rs. 10.32 Cr.
Rate of Return  30%
Break Even Point  44%

Note: ITI can modify the Capacity and Project Cost based on your requirement.

Contents of the Project Reports

Introduction
Uses and Applications
Properties
Market Position
Present Manufacturers
Detailed Process of Manufacture
Formulations
B.I.S. Specifications
Process Flow Sheet Diagram, Plant Layout,
Cost Economics with Profitability Analysis
Capacity
Land & Building Requirements with Rates
List & Details of Plant and Machinery with their Costs
Raw Materials Details/List and Costs
Power & Water Requirements
Labour/Staff Requirements
Utilities and Overheads
Total Capital Investment
Turnover
Cost of Production
Break Even Point
Profitability
Land Man Ratio
Suppliers of Plant & Machineries and Raw Materials
Cash Flow Statement
Repayment Schedule
Interest Chart
Depreciation Chart
Projected Balance Sheet for 5 Years etc.
